Neurolucida® Version 2022.2.2

Released July 2022

New imaging and data handling engines : MBF Bioscience software includes new image acquisition and image/data display technologies that maximize efficiency and speed throughout Neurolucida. Compile, save, load, display, and process your files much faster than before. These new imaging and data-handling engines employ intelligent image loading, concurrent usage of CPU cores, and multiple levels of data caching for efficient use of RAM and GPU resources. The speed and capabilities of Neurolucida software are now limited only by the resources of the computer on which it’s installed.



You will see major improvements in overall function and performance; highlights include:

  • Acquire much, much larger images than was previously possible—in the multiple terabyte range
  • Load very large image and data files noticeably faster than before—no lagging, no crashing
  • Handle millions of data points simultaneously—faster software response than ever before
  • Combine multiple data files, each containing massive numbers of markers and/or traced structures
  • Display image adjustments immediately in both the 2D and 3D windows—without clicking any buttons



Improved slide scanning workflow: The new imaging engine dramatically increases the size of images that can be acquired. The speed of image acquisition and assembly in the slide scanning workflow has also been improved. Benefits include:



  • Create larger slide-scans—at higher magnification and/or from larger specimens than possible in previous releases
  • Preview images before finalizing your large-image compilation settings
  • Include optional XY stitching for better image-tile alignment and cleaner compiled images
  • Mitigate uneven illumination artifacts in fluorescence imaging using (optional) intelligent, image-data based flatfield correction
  • View the amount of disk space needed for the slide scan before starting the image acquisition
  • Compile large images faster
  • Compile partial scans in the event an acquisition fails partway through



Software authorization and options: Easier software authorization—Neurolucida has a new, easier to use, licensing mechanism. License can be updated for renewal, or trial without having to connect to MBF staff.



  • Floating licenses are now available—share one Neurolucida license on more than one computer



More options for opening images

  • Indicate how you want Neurolucida software to handle and display your images
  • Open all images in container files such as Leica .lif and Zeiss .czi formats
  • Choose to display in a grid, stack images, or display on top of each other without stacking
  • Drag and drop to open files—the new Image Opener window makes it easier and more powerful



Neuron Tracing

  • Classify segments of trees in tree-editing mode to facilitate later analysis using Neurolucida Explorer analysis software
  • New End Tree choice when tracing trees enables you to continue tracing from any node, rather than automatically continuing tracing from the previous node
  • New Freehand Selection tools provide more options for selecting markers, contours, or traced structures
  • An additional option in the right-click menu for selecting objects in Trace mode: Select everything of this contour type



3D visualization window: The highly versatile 3D visualization environment includes a full suite of image optimization tools with state-of-the-art features that support your analysis and publication needs. Improvements include:



  • A new subvolume function in the 3D window enables you to easily and systematically focus on portions of images/image stacks
  • Color channel selection in the 3D window via a new Channel panel enables you to select one or more color channels to view and hide
  • New tool that clips tracings to a partial projection view



Other improvements



  • Updates to the Image Montage tool that support automatic z-alignment and the option to consider image names in the 2D image-alignment process
  • The default image-save format is now .xml
  • Research Resource Identifier (RRID) is now recorded in every xml data file
  • Simpler automatic exposure (in the camera settings) to achieve the target luminance for each image acquisition
  • Updated the Illumination Correction tool
  • Updated tool tips that display when hovering on buttons and tools throughout the software
  • New hardware support for the following:
    • Zeiss Apotome 3
    • Luminera CMOS camera
    • Basler cameras
  • New support for the following image formats
    • Big tiff
    • Hdf5
  • Custom Z offset is now available for use in Device command sequences

Neurolucida® Version 2021.1.1

Released May 2021

New Features and Enhancements:

  • Add ability to rotate individual points on a contour/tree
  • Added the ability to end tree tracing early, with a right click option. Added the ability to resume tracing by clicking on a node
  • Support for new Lumenera Lt-3200 CMOS color camera
  • Support for Zeiss MTB version 2.17.0.15
  • Support for Nikon RDK 1.4.0.115

Neurolucida® Version 2020.2.1

Released September 2020

New Features and Enhancements:

  • Basler cameras are now supported
  • Checkbox to “Use local help system” added to Preferences
  • PC serial nuber is now available in the About menu

Neurolucida® Version 2020.1.1

Released February 2020

New Features and Enhancements

  • Enables imporating of CSV or TXT files of regions or contour names.
  • Enables ability to search for names in the list of contours.
  • Added controls in the export tracing dialog for exporting images at a specific resolution.
  • Added an option in the Select Options to “select everything of this contour type”.
  • Added a new, fast cursor option in preferences. Selecting this option addresses potential issues with cursor delay.
  • New montage option ‘Order and align using image name’.

Neurolucida® Version 2019.1.3

Released July 2019

New Features and Enhancements

  • Cell detection workflow -step3: Added input text box to filtering slider under Parameters
  • Added font options and thickness to scalebar

Neurolucida® Version 2019.1.2

Released March 2019

New Features and Enhancements

  • Slide Scan workflow – step 1: fluorescent scan automatically selected when multichannel is enabled
  • Slide Scan workflow – step 8: “acquire sample image” unchecked by default
  • Slide Scan workflow – step 10: users no longer prompted to save background correction image (brightfield only)
  • File>Preferences: “show lens in Quick Access toolbar” added

Neurolucida® Version 2019.1.1

Released January 2019

New Features and Enhancements

  • Automatic cell detection workflow added to speed up detection process.
  • Slide scan workflow added to simplify slide scanning
  • Completely redesigned Preferences panels with a handy search functionality
  • Export: New “Set neuron colors” button and button to launch neuron preferences (#159494231); scalebar color and placement controls; new EMF detail slider.
  • Huron support: Huron jpeg files, definition for Huron file extension, support for Huron TIFF images
  • Markers: Ability to set multiple markers as locus simultaneously, either by right-clicking marker in the marker bar, or by selecting multiple markers and changing locus status from right-click menu.
  • 3D contour editing: Added button to reset all selected contours/shells back to Line mode display.
  • Slide scanning assembly operation: added notification about missing tiles or partial assembly; enabled assembly with missing tiles for partial acquisitions.
  • Sections: Display warning message when user attempts to change sections while moving to the next section.

Neurolucida® Version 2018.1.2

Released June 2018

New Features and Enhancements

  • Movie production in 3D: Redesigned and expanded functionality.
  • Mouse wheel: Function toggles between zooming and focusing depending on cursor location.
  • Tracing: Tracing commands in ribbon bar now disabled during Joy Track mode.
